Custom Agricultural Gearbox Spare Parts

ABOUT US
Your Trusted Partner in Agricultural Transmission Solutions
Hangzhou Hengnie Machinery Co., Ltd.
Founded in 2010, Hangzhou Hengnie Machinery Co., Ltd., located in Xiaoshan Industrial Park, Hangzhou, is a high-tech enterprise integrating R&D, production, sales, and technical services. It has been designated a National Specialized, Refined, and Innovative Enterprise. The company boasts a professional R&D team and numerous independent patents, focusing on the R&D and production of various agricultural machinery gearboxes and transmission components.
As a professional China Agricultural Gearbox Replacement Parts Supplier and custom gearbox spare parts company, Offering a complete range of products, it can customize to order and provides intelligent product customization services. The company owns the brands "ND," "AG," and "DY," and its products are compatible with various agricultural machinery and intelligent products. Over 85% of its products are exported to Europe, America, and Australia. With superior quality, technical strength, and excellent service, it has won global customer recognition. We sincerely welcome customers from all walks of life to cooperate for mutual benefit!
Hangzhou Hengnie Machinery Co., Ltd.

Honor

  • honor
  • honor
  • honor
  • honor
  • honor
  • honor

News

Contact us now

Industry Knowledge Expansion

Hangzhou Hengnie Machinery Co., Ltd. is a China-based Agricultural Gearbox Replacement Parts Supplier focused on agricultural machinery transmissions. Our Gearbox Spare Parts & Components range covers cylindrical gears, bevel gears, power transmission shafts and PTO shafts for maintenance, repair and OEM production. We manufacture these components in our Xiaoshan factory using precision machining, heat treatment and in-house quality control, and we support both off-the-shelf standard parts and matched custom sets.

Replacement programs exist to return a gearbox to its original working point, reduce unscheduled stops and keep the implement in the field. We therefore supply parts as individual line items, as matched gear sets, or as part of a complete drive package with a new gearbox and accessories. Because we also build complete agricultural gearboxes, the spare parts range is designed around the same housing families, ratios and mounting conventions used on our standard and application-specific gearboxes.

What the Gearbox Spare Parts & Components Range Covers

Our Gearbox Spare Parts range is organized into four component families corresponding to the main wearing and load-carrying elements inside agricultural gearboxes. Each family is machined to serve a specific transmission function and can be supplied as a single replacement part or as a matched set.

Component family Manufacturing approach Typical transmission role
Cylindrical Gears Precision-machined tooth profile, hardened after heat treatment Parallel-shaft reduction stages, mixer and conveyor drives
Bevel Gears Heat-treated spiral or straight bevel sets for right-angle power reversal Right-angle gearboxes, power harrow drives, baler and rake inputs
Power Transmission Shafts Alloy steel integral forging with controlled coaxiality Input, output and intermediate shafts inside the gearbox
PTO Shafts Driveline shafts with splined or yoke ends matched to the machine Tractor power take-off connection to implements

For matched pairs, we manufacture the gear and pinion together so that tooth contact pattern, backlash and center distance behave like the original gear set. This matters when replacing only one side of a pair in a parallel-shaft stage or right-angle drive; installing an unmatched single gear can create noise, uneven load distribution and early wear.

Application Fit in Agricultural Machinery

Agricultural gearboxes run under dust, mud, moisture, vibration, alternating load and frequent start-stop cycles. Replacement components must handle those conditions without changing the original housing or mounting geometry. The four families fit machinery categories that we also cover as complete gearboxes, including rotary tillage equipment, power harrows, round balers, manure spreaders, sprayers, corn headers and rotary rakes.

  • Cylindrical gears fit parallel-shaft reducers, mixer drives, fertilizer spreaders and conveyor or elevator gearboxes where input and output shafts are parallel.
  • Bevel gears fit right-angle steering boxes, spiral bevel drive units, rotary rake transmissions and baler or sprayer gearboxes where power must change direction.
  • Power transmission shafts serve as the input, output or intermediate shafts inside these gearboxes, carrying gear meshing forces and transmitting torque to the working tool.
  • PTO shafts address the driveline between tractor and implement, including shaft length adaptation, yoke selection and spline matching.

This application focus is central to our engineering approach. A replacement part for a power harrow gearbox, baler gearbox or corn header gearbox is selected by its duty point, not only by its outside dimensions. We use the machine type and load spectrum to confirm material grade, heat treatment and whether a matched set is the safer supply option.

Material, Heat Treatment and Critical Specifications

Cylindrical gear teeth are precision machined so that the tooth profile provides accurate meshing, smooth running and low operating noise. After hardening heat treatment, the tooth surface has improved wear resistance and pitting resistance, allowing the gear to carry continuous load in a parallel transmission stage. Bevel gears are heat treated to absorb instantaneous impact torque during start-stop and fluctuating field load, while keeping power commutation loss low and transmission response sensitive.

Power transmission shafts are forged as integral alloy steel blanks with strictly controlled coaxiality to avoid eccentric vibration at high speed and to resist long-term alternating torsion and radial pressure. Shaft journals, bearing seats, keyways and spline forms are machined in the same setup where possible, so the replacement shaft maintains concentricity with the gear train.

When we build a replacement, the governing specifications are module or diametral pitch, tooth count, pressure angle, helix angle, face width, backlash class and surface hardness for gears; and shaft diameter, bearing seats, keyway or spline form, overall length and concentricity for shafts. Where the original drawing is incomplete, we reverse-engineer these values from the worn part or from the gearbox housing itself.

Configuration Options and Custom Engineering Support

Replacement parts are not always stock items. We support three procurement routes:

  • Off-the-shelf standard parts for common agricultural gearbox sizes and series, enabling quick field repair when the original part is a standard configuration.
  • Matched sets where gear, shaft and sometimes bearings are supplied together to maintain original backlash and load distribution.
  • ODM/OEM development where you supply drawings, samples or working-condition data and we develop the component, the transmission package, or an upgraded version of an existing drive.

Customized manufacturing based on drawings or samples is our core business. We can adjust tooth profile, material grade, heat treatment depth, shaft extension, keyway position and mounting details to match the machine. For larger projects, we offer a one-stop drive system package covering gearboxes, accessories and control systems, with selection support and installation guidance so that the spare parts program and the new equipment program can be managed from the same supplier.

Quality Control, Inspection and Acceptance

Quality control runs through incoming material control, process monitoring and final product inspection, supported by professional testing equipment. For gears and shafts, the checks cover dimensional accuracy, tooth geometry, surface finish, hardness, concentricity and assembly status. For a complete gearbox or a gearbox rebuilt with our parts, sealing tests are also performed to confirm protection against agricultural dust and moisture.

The factory follows an ISO-based quality management system and uses standardized assembly lines with advanced processing equipment in key operations. Production scheduling supports parallel batches of different models, so a custom gear and a standard shaft can be manufactured in the same production window. For customized components, we can organize performance tests and factory acceptance tests before shipment, and we sign off inspection reports, test records and the full set of export shipping documents.

Documentation, Packaging and Delivery Scope

After order confirmation, we coordinate production internally and track each manufacturing milestone so that schedules remain visible. Technical drawings, specification manuals and installation guides are supplied for equipment assembly and commissioning. Export packaging is selected according to destination and logistics route, with protection designed for long-distance sea freight and cross-border transport.

After delivery, our engineering team remains available for remote technical consultation, fault analysis and working-condition suggestions. Replacement parts restore the original duty without requiring a new housing, so the maintenance team can shorten downtime and return equipment to field operation faster. We also collect application feedback and use it for product iteration, particularly when a repeated failure points to a design weakness rather than normal wear.

Information We Use to Configure Your Solution

To prepare a precise quotation and production plan, we need the following project data. You can send a sample or worn component if no drawing exists; our engineering team measures it and confirms the required tooth and shaft geometry before producing the replacement.

Project input What it defines
Original gearbox model, series or nameplate Housing family, ratio, shaft arrangement and mounting convention
Drawing, sample or worn part Tooth geometry, backlash, material, shaft length and keyway or spline details
Machine type and duty Load spectrum, impact conditions and heat-treatment requirement
Input speed, PTO speed and rated torque Tooth loading, shaft strength and allowable operating envelope
Quantity and delivery target Batch size, stock decision and production scheduling

Send this information together with a machine photo or an original gearbox nameplate if available. We use these facts to confirm compatibility before producing replacement parts, which reduces the risk of multiple revisions later and keeps the proposal aligned with the actual service condition.

Frequently Asked Questions

Can you match replacement parts without drawings?
Yes. Customized manufacturing based on drawings or samples is our core business. If only a worn gear or shaft is available, we measure tooth geometry, center distance, bearing positions and shaft details, then produce the part as a single item or as a matched set.

What is included in the Gearbox Spare Parts & Components range?
The range covers cylindrical gears, bevel gears, power transmission shafts and PTO shafts. Standard configurations can be supplied off the shelf, while non-standard dimensions, materials and heat-treatment levels are handled through custom production.

Can replacement parts be supplied together with a new gearbox?
Yes. Our one-stop drive system approach covers gearboxes, accessories and control systems. For service programs, we can supply the spare part alone, as a matched set, or as part of a complete drive package for the same machine.

How do you control the quality of replacement gears and shafts?
We rely on incoming material control, process monitoring and final product inspection. Checks cover dimensional accuracy, tooth geometry, surface finish, hardness, concentricity and sealing for complete gearboxes. Custom components can also go through performance tests and factory acceptance tests.

How do you help reduce field downtime?
Standard parts are supplied directly for servicing, and matched sets reduce fitting time by preserving original backlash and load distribution. After delivery, we provide technical documentation, remote consultation and fault analysis so the maintenance team can complete the repair and return the machine to operation quickly.
